CY-IP1201 IP speaker

Usage:

1. Professional integrated wall mount network audio decoding speaker with built in network decode module, digital stereo constant resistant power amplifier and Hi-fi loudspeaker.

2.Indoor speaker can be used by directly connecting with internet. Each speaker can be an individual zone.


Description:

1. Integration with IP network audio decode, digital power amplifier and speaker.

2. Using DXVA to receive the music sent from server for real-time playing and receive one-way broadcast paging.

3. Using high speed industrial dual-core (ARM+DSP) chip with fast starting time less than 1 second.

4. Built in stereo power amplifier with output impedance of 8Ω/2x20W and sound quality is CD level.

5. Built in 1 MIC input, 1 stereo line input, 1 audio line output

6. 1 of RJ45 10/100M network interface for connecting network directly

7. 1 group of auxiliary speaker output for connecting a constant impedance speaker.

8. Treble, bass, master volume knob for convenient control.

9.It can control the volume remotely by IP network broadcast software.

10.Built in 6.5” bass + 3” treble hi-fi speaker unit.

11.Standby power rate is less than 2W which meet the environmental standard.


  • Specifications

Network  interface

standard  RJ45 input

Supported  protocol

TCP/IP,UDP,IGMP

Audio  format

MP3,  MP2

Sampling  rate

8K-48KHz

Transmission  rate

100Mbps

Audio  mode

16  stereo CD sound quality

Output  frequency

80Hz-16KHz

Harmonic  distortion

≤ 1%

S/N  ratio

>70db

External  speaker input impedance and rated power

8Ω, 2x15W industrial standard binding post

AUX  input level

350mv industrial  standard binding post

Line  input level

1000mv

Line  output impedance

470Ω

MIC  input sensitivity

5mv

Environmental  temperature

5℃-40℃

Environment  humidity

20%-80%  relative humidity, non condensing

Power  dissipation

≤40W

Input  power

AC220V/50Hz
