CY-IP918 outdoor with LED screen IP network intercom terminal

Product Usage:

1, professional outdoor key help IP network intercom terminal, with LED display, a key to complete full-duplex two-way intercom, simple and quick operation;

2, designed for safe cities, large parks, tunnels, mines and other places designed, and can be used to broadcast and play background music.



product description:

1, outdoor all-weather IP network a key help intercom terminal, with LCD display, a key to complete full-duplex two-way intercom, simple and quick operation;

2, the panel configuration of the bright, widescreen LED display dot matrix, you can clearly display the location of the name and help number and other information, the LED screen display content can be customized;

3, real-time display of the current state of operation information, such as the button after the show "call" and other functions;

4, the device uses embedded computer technology and DSP audio processing technology design; high-speed industrial-grade chip, start time is less than 1 second;

5, durable, all-metal shell riot waterproof, can be fixed on the vertical bar; 6, built-in high-sensitivity microphone and monitor speakers to achieve intercom pickup and live sound collection monitoring, support hands-free calls;

7, optional 8Ω / 60W digital amplifier, to meet the needs of different occasions,

8, with all the way audio line input and all the way audio line output port for special places of public address and sound acquisition;

9, with short-circuit output interface, can be used to monitor linkage;

10, high degree of protection design, the overall use of alloy material and anti-disassembly screws, and explosion-proof, waterproof, anti-acupuncture; Ethernet port where you can access, cross-network and cross-routing.



  • Specifications
产品技术参数表
型号 CY-IP918
网络接口 1路标准RJ45网络接口
传输速率 10/100Mbps
音频格式 MP2/MP3
支持协议 TCP/IP、UPP、IGMP(组播)
采样率 8K~48KHz
音频模式 16位立体声CD音质
信噪比 >75dB
谐波失真 ≤0.3%
频率响应 20Hz~16KHz
短路输出 1路
线路输入路数、电平 1路、350mV
线路输出路数、电平 2路、775MV
功放功率、阻抗 2W、8Ω(可定制大功率功放)
输入电源 DC12V
